| Model |
|
HS-AHD-T032A8
|
|
Pick up device
|
|
1/2.8” SONY CMOS : 2.0 Mega
|
|
Solution
|
|
2440H + SONY 322
|
|
Resolution
|
|
1920(H) x 1080(V) @ 30fps
|
|
Video Output
|
|
AHD
|
|
Min. Illumination
|
|
0.01 lux
|
|
Synchronization
|
|
Internal
|
|
Scanning System
|
|
2:1 Interlace
|
|
IR Distance
|
|
60M (12pcs matrix LED)
|
|
Lens Type
|
|
Semi-auto Vari-focal Lens: 2.8~12 mm
|
|
Electronic Shutter
|
|
Auto 1/60 (1/50) ~ 1/50,000 sec / FLK
|
|
S/N Ratio
|
|
More than 60 dB(AGC OFF)
|
|
Focus & Zoom Adjustment
|
|
Electronics
|
|
Control
|
|
CoC (Control Over Coaxial)
|
|
2DNR
|
|
Yes
|
|
3DNR
|
|
Yes
|
|
Coaxial Cable Transmition Distance (3C/5C)
|
|
300 / 500 M
|
|
Twisted Cable Transmition
(Cat 5.e standard)
|
|
300 M
|
|
Power Source
|
|
DC12V ± 10% / 1A
|
|
Operating Temperature
|
|
-10℃ ~ 50℃ (14℉ ~ 122℉ )
|
|
Storage Temperature
|
|
-20℃ ~ 70℃ (-4℉ ~ 158℉)
|
|
Dimension
|
|
286.8mm x ø94.5 (Diameter)mm
|
|
Weatherproof
|
|
IP66
|
